Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-59
Procedure
The procedure below explains [DTMF Send] > [DTMF Continuous] as an example.
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Use the [ ] button to select [Fax/Scanner Diag], and press the OK button.
3. Press the OK button.
4. Use the [ ] button to select [Relay/Signal Test], and press the OK button.
5. Use the [ ] button to select [DTMF Send], and press the OK button.
6. Press the OK button.
7. Use the [ ] or [ ] button to change the value and then press the OK button to start sending the
signal.
8. To stop sending the signal, press the Back button.
9. Press the Back button to return to the [Fax Scanner Diag] screen.
10. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Fax/Scanner Diag
Board Test
Board Test
All test
Board Test
Relay/Signal Test
Relay/Signal Test
Relay Test
Relay/Signal Test
DTMF Send
DTMF Send
DTMF Continuous
DTMF Continuous
DTMF:0
DTMF Continuous
DTMF:5
DTMF Continuous
DTMF:5
Now Sending Signal
DTMF Continuous
DTMF:5
Fax/Scanner Diag
Board Test

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
