Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-212
Regi Clutch (PL15.1.8)
4 Check the power to the Feed Clutch (+24 VDC)
Close the interlock switch(es), and check if the voltage
between the MCU Board ground and the P/J39-3 pin is about
+24 VDC.
Replace the Feed
Clutch.
Refer to
“+24 VDC Power
FIP” on
page 2-222.
Step Check Yes No
Possible causative parts:
• Regi Clutch (PL15.1.8)
• Regi Harness Assembly (PL15.2.8)
• MCU Board (PL18.1.13)
1 Check the Regi Clutch operation
Execute Digital Output diagnostic test 071-010, and check
the Regi Clutch operation.
Does the Regi Clutch function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Regi Clutch connection
Check the connection between the Regi Clutch and the MCU
Board.
Are P/J234 and P/J23 connected securely?
Go to step 3. Connect P/J234
and P/J23
securely.
3 Check the Regi Clutch resistance value
Turn off the power, take off the Regi Clutch, and check the
wire wound resistance between both terminals.
Is the wire wound resistance value 240 ohm (20 degrees C)?
Go to step 4. Replace the Regi
Clutch.
4 Check the power to the Regi Clutch (+24 VDC)
Close the interlock switch(es), and check if the voltage
between the MCU Board ground and the P/J23-1 pin is about
+24 VDC.
Replace the Regi
Clutch.
Refer to
“+24 VDC Power
FIP” on
page 2-222.
Step Check Yes No

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
