Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-213
Path Sensor [550 Option Main Feed Assembly] (PL10.2.1)
Step Check Yes No
Possible causative parts:
• Path Sensor [550 Option Main Feed Assembly] (PL10.2.1)
• C2 Size Harness Assembly (PL10.1.14)
• Drawer 1 Feeder Harness Assembly (PL10.1.13)
• Main Harness Assembly (PL18.2.3)
• 550 Option Feeder Board (PL10.1.10)
• MCU Board (PL18.1.13)
1 Check the Path Sensor operation
Execute Digital Input diagnostic test 071-117, and check the
Path Sensor operation.
Does the Path Sensor function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Path Sensor connection
Check the connection between the Path Sensor and the 550
Option Feeder Board.
AreP/J4214 and P/J421 connected securely?
Go to step 3. Connect P/J4214
and P/J421
securely.
3 Check the continuity between the Path Sensor and the 550
Option Feeder Board
Is each cable of P/J4214<=>P/J421 continuous?
Go to step 4. Replace the C2
Size Harness
Assembly.
4 Check the power to the Path Sensor (+3.3 VDC)
Check if the voltage between the 550 Option Feeder Board
ground and the P/J23-6 pin is about +3.3 VDC.
Replace the Path
Sensor [550
Option Main
Feed Assembly].
Go to step 5.
5 Check the power to the 550 Option Feeder Board (+3.3 VDC)
Check if the voltage between the 550 Option Feeder Board
ground and the P/J419-4 pin is about +3.3 VDC.
Replace the 550
Option Feeder
Board.
Go to step 6.
6 Check the power from the MCU Board (+3.3 VDC)
Check if the voltage between the MCU Board ground and the
P/J27-7 pin is about +3.3 VDC.
Go to step 7. Refer to
“+3.3 VDC Power
FIP” on
page 2-224.
7 Check the PWBA Assembly FEED connection
Check the connection between the PWBA Assembly FEED
and the MCU Board.
Are P/J419, DP/J271, and P/J27 connected securely?
Replace the
Drawer 1 Feeder
Harness
Assembly
and the
Main Harness
Assembly.
Connect P/J419,
DP/J271, and
P/J27 securely.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
