Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-46
Parts List 18.1 Phaser 6600 Electrical (1/2)
Item Name Part Number
1— —
2 Guide_ Harnness_ Top —
3— —
4 Guide_ Harnness_ Exit —
5 Cover Harness Top —
6 Guide Harness Top L (Left Top Harness Guide) —
7 Guide_ Harness_ Erase_ CRM —
8 Housing _ Assy_ Charge_ Deve (Developer Charge Housing Assembly) —
9 Housing_ Assy_ Charge_ Deve_ Out (Outer Developer Charge Housing Assembly) —
10 Guide Harness Video (Video Harness Guide) —
11 Guide Harness L (Left Harness Guide) —
12 Plate MCU (MCU Plate) —
13 PWBA MCU (MCU Board) 960K67961
14 PWBA HVPS XD (Development HVPS Board) 105K26092
15 Plate Earth HV (HV Ground Plate) —
16 Housing Assy Gnd Fusing (Fuser Ground Housing Assembly) —
17 Varistor, NVD10UCD1100 —
18 Plate Window —
19 Plate ESS Top —
20 Plate_ ESS_ Bottom —
21 Kit Package Hard Disk —
22 PWBA ESS (IP Board) 960K60494
23 Plate ESS Front (Front IP Board Plate) —
24 Plate ESS Rear (Rear IP Board Plate) —
25 — —
26 — —
27 Kit Packaging Wireless (Wireless Kit) —
28 PWBA HVPS TR (Transfer HVPS Board) 105K26102
29 Guide_ Harness_ PH —
30
Housing_ Assy_ Wire_ TR_IN (
Inner Transfer Wire Housing Assembly)
—
