Xerox WorkCentre 6605 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-47
31 AC In (AC Inlet) 604K76361
32 Guide Harness LV AC —
33 Cap LV Bottom —
34A LVPS 110V 105K30560
34B LVPS 220V 105K30570
35 Guide Harness R (Right Harness Guide) —
36 Holder Drower —
37 Housing Assy Wire TR Out —
38 Bracket ESS SFP (IP Board Bracket) —
39 Fdr Drawer1 913W12104
40 — —
41 — —
42 — —
43 PWBA EEPROM XPRO (EEPROM Board) —
44A Power Cord US 110V 675K43778
44B Power Cord TAA 220V Euro —
44C Power Cord TAA 220V UK —
45 Sensor-Photo INT (Interlock Photo Sensor) —
46 — —
47 Harness Assy BTR —
99 Varistor Assy (with16,17) 848K69221
Parts List 18.1 Phaser 6600 Electrical (1/2)
Item Name Part Number

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
