DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
46
Example
To display the 802.1X port level configurations:
DGS-3000-26TC:admin#show 802.1x auth_configuration ports 1
Command: show 802.1x auth_configuration ports 1
Port Number : 1
Capability : None
AdminCrlDir : Both
OpenCrlDir : Both
Port Control : Auto
QuietPeriod : 60 sec
TxPeriod : 30 sec
SuppTimeout : 30 sec
ServerTimeout : 30 sec
MaxReq : 2 times
ReAuthPeriod : 3600 sec
ReAuthenticate : Disabled
Forward EAPOL PDU On Port : Enabled
Max User On Port : 16
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh
config 802.1x capability 4-11
Description
This command is used to configure the port capability.
Format
config 802.1x capability ports [<portlist> | all] [authenticator | none]
Parameters
ports - Specify a range of ports to be configured.
<portlist> - Enter the list of ports used for the configuration here.
all - Specify all ports to be configured.
authenticator - Specify the port that will enforce authentication before allowing access to
services that are accessible from that port. This port will adopt the authenticator role.
none - Disables authentication on the specified ports.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To configure the port capability:
