DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
794
Format
delete super_vlan [<vlan_name 32> | vlanid <vlanid 1-4094>]
Parameters
<vlan_name 32> - Enter the VLAN name used here. This name can be up to 32 characters long.
vlanid - Specify the VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To delete the super VLAN by specify the VLAN ID 10:
DGS-3000-26TC:admin# delete super_vlan vlanid 10
Command: delete super_vlan vlanid 10
Success.
config sub_vlan 81-4
Description
This command is used to configure the IP range of the sub-VLAN.
A sub-VLAN can has one or more IP ranges. Configuring IP range of sub-VLAN can reduce the
ARP traffic in the super VLAN. That is multiple IP (ranges) is allowed to map to one sub-VLAN.
One IP can not map to multiple sub-VLANs, if one IP is mapped to multiple VLAN it may cause
traffic forwarding to the wrong VLAN.
Format
config sub_vlan [<vlan_name 32> | vlanid <vlanid 1-4094>] [add | delete] ip_range <ipaddr>
to <ipaddr>
Parameters
<vlan_name 32> - Enter the VLAN name used here. This name can be up to 32 characters long.
vlanid - Specify the VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
add - Specify the IP range of the sub-VLAN that will be added.
delete - Specify the IP range of the sub-VLAN that will be deleted.
ip_range - Specify the IP range of the sub-VLAN that will be used.
<ipaddr> - Enter the starting IP address used here.
to - Specify that the next IP address will be the ending IP address.
<ipaddr> - Enter the ending IP address used here.
