SV-ADAHRS-200/201 Installation and Configuration
5-10 SkyView System Installation Guide - Revision AA
Mounting hardware is not provided with the SV-ADAHRS-200/201. The mounting tabs on each
side of the module have holes sized for #10 fasteners, but it is up to the installer to decide how
the SV-ADAHRS-200/201 will be secured to the aircraft.
We recommend the use of button-head style non-ferrous (brass recommended) fasteners in
this location. Follow recommended torque practices when tightening the mounting hardware.
Do not rivet the SV-ADAHRS-200/201 to the aircraft as this will hinder future removal if
necessary.
Do not use a magnetic driver when installing the SV-ADAHRS-200/201. Doing so has
the potential to affect the factory magnetic calibration.
If you are installing an SV-ADAHRS-200 and SV-ADAHRS-201 using the Dynon Avionics Dual
ADAHRS Mounting Kit, follow the installation instructions below (Figure 49).
