SV-EMS-220/221 Installation and Configuration
7-6 SkyView System Installation Guide - Revision AA
compatible with SkyView. Use the tools in this section as well as the worksheet on page 24-1
when planning sensor and transducer installation.
SV-EMS-220/221 Engine Sensor Kits
Dynon Avionics offers kits of sensors and appropriate harnesses for several common engines.
Note that the Fuel Flow Sensor, P/N 100403-003 is optional; it is not included in any Dynon
Avionics Engine Sensor Kit.
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101690-000
Kavlico 0 – 15 PSI Liquid Pressure
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
101693-000
Kavlico 0 – 150 PSI Liquid Pressure
Temp – Carb Air
1
100468-000
1/4-28 UNF, -50°F – 150°F
Temp – CHT
4
100404-000
Type J (CHT) Thermocouple,
Adjustable Bayonet 3/8-24 UNF
Temp – EGT
4
100405-000
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
Temp – Oil
1
100409-001
5/8-18 UNF, 100°F – 240°F
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-001
4 CHT and 4 EGT, 6’
Table 17 – EMSKIT-L4C, P/N 101711-000 – Lycoming / Continental / Superior 4 Cylinder, Carbureted
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101716-000
Kavlico 0 – 50 PSI Liquid Pressure
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
101693-000
Kavlico 0 – 150 PSI Liquid Pressure
Temp – CHT
4
100404-000
Type J (CHT) Thermocouple,
Adjustable Bayonet 3/8-24 UNF
Temp – EGT
4
100405-000
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
Temp – Oil
1
100409-001
5/8-18 UNF, 100°F – 240°F
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-001
4 CHT and 4 EGT, 6’
