SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-7
Table 18 – EMSKIT-L4F, P/N 101711-003 – Lycoming / Continental / Superior 4 Cylinder, Fuel Injected
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101690-000
Kavlico 0 – 15 PSI Liquid Pressure
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
101693-000
Kavlico 0 – 150 PSI Liquid Pressure
Temp – Carb Air
1
100468-000
1/4-28 UNF, -50°F – 150°F
Temp – CHT
4
100404-000
Type J (CHT) Thermocouple,
Adjustable Bayonet 3/8-24 UNF
Temp – EGT
4
100405-000
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
Temp – Oil
1
100409-001
5/8-18 UNF, 100°F – 240°F
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-002
6 CHT and 6 EGT, 6’
Table 19 – EMSKIT-L6C, P/N 101711-001 – Lycoming / Continental / Superior 6 Cylinder, Carbureted
