SV-EMS-220/221 Installation and Configuration
7-8 SkyView System Installation Guide - Revision AA
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101716-000
Kavlico 0 – 50 PSI Liquid Pressure
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
101693-000
Kavlico 0 – 150 PSI Liquid Pressure
Temp – CHT
4
100404-000
Type J (CHT) Thermocouple,
Adjustable Bayonet 3/8-24 UNF
Temp – EGT
4
100405-000
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
Temp – Oil
1
100409-001
5/8-18 UNF, 100°F – 240°F
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-002
6 CHT and 6 EGT, 6’
Table 20 – EMSKIT-L4F, P/N 101711-004 – Lycoming / Continental / Superior 6 Cylinder, Fuel Injected
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101690-000
Kavlico 0 – 15 PSI Liquid Pressure
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
Included on engine, not supplied by Dynon Avionics
Temp – CHT
2
Included on engine, not supplied by Dynon Avionics
Temp – EGT
2
100405-001
Type K (EGT) Thermocouple,
0.75” – 1.25” Hose Clamp
Temp – Oil
Included on engine, not supplied by Dynon Avionics
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-004
0 CHT and 2 EGT, 6’
Table 21 – EMSKIT-RTX, P/N 101711-002 – Rotax 912 ULS
