Dynon Avionics SkyView Classic - Page 149

SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-9
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Fuel Flow
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Pressure – Fuel
1
101716-000
Kavlico 0 – 50 PSI Liquid Pressure
Pressure – Manifold
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Pressure – Oil
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Temp – Coolant
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Temp – EGT (1-4)
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Temp – Oil
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Voltage – Lane A Bus
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Voltage – Lane B Bus
Sensor data provided by Rotax 912 iS ECU via CAN BUS
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Table 22 – EMSKIT-RTXiS, P/N 101711-007 – Rotax 912 iS
Sensor Type
Qty
Dynon
Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Pressure – Fuel
1
101690-000
Kavlico 0 – 15 PSI Liquid Pressure
Pressure – Oil
1
Included on engine, not supplied by Dynon Avionics
Temp – CHT
4
100578-000
Type J (CHT) Thermocouple,
12mm Ring Terminal
Temp – EGT
4
100405-002
Type K (EGT) Thermocouple,
1.00” – 1.75” Hose Clamp
Temp – Oil
Included on engine, not supplied by Dynon Avionics
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
1
100399-001
4 CHT and 4 EGT, 6’
Table 23 – EMSKIT-J22, P/N 101711-005 – Jabiru 2200
