Sensor Type
Qty
Dynon Avionics
P/N
Description
Amps Shunt
1
100412-000
0-60 Amps, 1mV=1A
Fuel Flow
Pressure – Fuel
1
Included on engine, not supplied by Dynon Avionics
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
Included on engine, not supplied by Dynon Avionics
Temp – Air Box
1
Skykit Airbox Temp Sensor (1/8-27 NPT),
not supplied by Dynon Avionics
Temp – Carb Air
1
100468-000
1/4-28 UNF, -50°F – 150°F
Temp – CHT
2
Included on engine, not supplied by Dynon Avionics
2
Alternative CHT: 10mm Ring Type J Thermocouple,
Not supplied by Dynon Avionics
Temp – EGT
4
100405-001
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
4
Alternative EGT: Westach 712-4D6K,
Not supplied by Dynon Avionics
4
Alternative EGT: UMA 2B30,
Not supplied by Dynon Avionics
Temp – Oil
1
Included on engine, not supplied by Dynon Avionics
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
Varies – choose from:
100399-004: 2 CHT (Type J), 0 EGT (Type K), or
100399-001: 4 CHT (Type J), 4 EGT (Type K)
Table 26 – Recommended Sensors for Rotax 914
(No Dynon Avionics kit of sensors currently available – purchase individual sensors)
