SV-EMS-220/221 Installation and Configuration
7-12 SkyView System Installation Guide - Revision AA
Sensor Type
Qty
Dynon Avionics
P/N
Description
Fuel Flow
1
100403-003
1/4” Female NPT, 0.6 – 70 GPH
Pressure – Fuel
1
Included on engine, not supplied by Dynon Avionics
Pressure – Fuel
1
101716-000
Kavlico 0 – 50 PSI Liquid
Pressure – Manifold
1
100434-000
0” – 60” hg, 1/8” hose
Pressure – Oil
1
101693-000
Kavlico 0 – 150 PSI Liquid
Temp – Carb Air
1
100468-000
1/4-28 UNF, -50°F – 150°F
Temp – CHT
2
Included on engine, not supplied by Dynon Avionics
2
Alternative CHT: 10mm Ring Type J Thermocouple,
Not supplied by Dynon Avionics
Temp – Coolant
1
100409-000
0 - 250°F, 1/287 NPT
Temp – EGT
4
100405-001
Type K (EGT) Thermocouple,
1.00” – 2.25” Hose Clamp
4
Alternative EGT: Westach 712-4D6K,
Not supplied by Dynon Avionics
4
Alternative EGT: UMA 2B30,
Not supplied by Dynon Avionics
Temp – Coolant
1
100409-000
0 - 250°F, 1/287 NPT
Temp – Oil
1
Included on engine, not supplied by Dynon Avionics
Wiring Harnesses
Harness – Main Sensor
1
100399-000
All sensors but CHT and EGT, 6’
Harness – CHT/EGT
Varies – choose from:
100399-004: 2 CHT (Type J), 0 EGT (Type K), or
100399-001: 4 CHT (Type J), 4 EGT (Type K)
Table 27 – Recommended Sensors for Viking
SV-EMS-220/221 Wire Harnesses
Engine and environmental sensors and transducers are connected to the SV-EMS-220/221 via
two connectors on the module: one D37M and D25F. Dynon Avionics offers premade wire
harnesses which break out the pins on these connectors and it is highly recommended that
installers use these wire harnesses. Table 28 below lists these wire harnesses and their
respective connections to the SV-EMS-220/221.
Dynon Avionics P/N
Description
Mates with…
100399-000
EMS D37F Main Sensor Harness
SV-EMS-220/221 D37M
100399-001
EMS D25M EGT/CHT 4-cylinder
Thermocouple Wire Harness
SV-EMS-220/221 D25F
100399-002
EMS D25M EGT/CHT 6-cylinder
Thermocouple Wire Harness
SV-EMS-220/221 D25F
100399-004
EMS D25M EGT 2-cylinder
Thermocouple Wire Harness
SV-EMS-220/221 D25F
