SV-EMS-220/221 Installation and Configuration
7-38 SkyView System Installation Guide - Revision AA
The latest EMS sensor definitions file must be downloaded from the SkyView Downloads
page at http://downloads.dynonavionics.com and loaded onto each display. To verify,
check SETUP MENU > SYSTEM SETUP > EMS SETUP > SENSOR DEBUG DATA. The date of
the sensor definition file currently loaded on the display will be displayed on the top line
of the right window.
See the EMS Engine Setups area at http://downloads.dynonavionics.com to download a
file that sets up 912 iS-specific pin mappings. It also positions 912 iS-specific widgets on
the EMS pages (such as ECU Lane A/B voltage, which must be monitored per Rotax).
As of SkyView Software v13.0, these 912 iS-specific widgets were added:
o Throttle Position
o Cold Start Assistance (color coding on the Throttle Position widget)
o Power / ECO mode state
The Kavlico 50 PSI fuel pressure sensor (Dynon Avionics P/N 101716-000) is the ONLY
sensor that can be used to monitor fuel pressure when SkyView is used to monitor a 912
iS engine. Additionally, when using the required 50 PSI Kavlico sensor for measuring fuel
pressure, “KAV 50 PSI DIFFERENTIAL (101716-000)” sensor must be selected for fuel
pressure sensor selection under SETUP MENU > EMS SETUP > SENSOR INPUT MAPPING
instead of the KAVLICO 50PSI FLUID PRESS selection that is used for other
configurations. If you use the EMS Engine Setup for the 912 iS that is available from the
link above, this selection and setup is already correctly performed for you.
Fuel pressure on the 912 iS is measured with respect to the air box pressure. To be able
to display correct fuel pressure, SkyView must receive the following data:
Manifold pressure (via CAN bus from Rotax 912 iS ECU), and
Barometric pressure (via SkyView Network from SkyView SV-ADAHRS-200/201).
