Dynon Avionics SkyView Classic - Page 179

SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-39
Example 9-cylinder Radial (Using Dual SV-EMS-220s,
100399-000, 100399-001, 100399-002 Harnesses)
PRIMARY EMS MODULE with 100399-000 Harness
Pin
EMS 37-pin Harness
Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Red
Battery Voltage (Voltmeter Input)
2
Yellow or Unwired
No connection
3
Black
Ground
4
Violet/Blue
Elevator Position Potentiometer
5
Black
Ground
6
White/Yellow
150 PSI Oil Pressure (101693-000)
7
White/Brown
Oil Temperature P/N 100409-000
8
Brown
15 PSI Fuel Pressure (101690-000) or
50 PSI Fuel Pressure (101716-000)
9
Brown/Blue
Heated AOA/Pitot Probe status (contact input)
10
Brown/Yellow
No connection
11
Orange
No connection
12
Yellow
No connection
13
Black
Ground
14
Yellow
Fuel Flow P/N 100403-003
15
Red
Fuel Flow Power P/N 100403-003
16
Black
Ground
17
Black
Ground
18
White/Red
Manifold Pressure Sensor Power (+5 Volt) and
Kavlico Pressure Sensors (+5 Volt)
19
White/Black
No connection
20
Orange/Brown
Fuel Level Left (Resistive)
21
Orange/Blue
Fuel Level Right (Resistive)
22
Violet/Yellow
Flaps position Potentiometer
23
Violet/Green
No connection
24
Orange/Green
Ammeter Shunt + P/N 100412-000
25
Orange/Violet
Ammeter Shunt – P/N 100412-000
26
Green/Red
Manifold Pressure P/N 100434-000
27
Open
No connection
28
Open
No connection
29
Yellow/Green
Optional External Alarm Indicator
30
Black
No connection
31
White/Orange
No connection
32
White/Green
RPM Left (Standard)
33
White/Blue
RPM Right (Standard)
34
Blue
No connection
35
Green
No connection
36
Blue or Unwired
No connection
37
Green or Unwired
No connection
Table 48 – Example 9-cylinder Radial Primary SV-EMS-220 37-pin Connector Sensor Map
