Dynon Avionics SkyView Classic - Page 180

SV-EMS-220/221 Installation and Configuration
7-40 SkyView System Installation Guide - Revision AA
PRIMARY EMS MODULE with 100399-002 Harness
Pin
EMS 25-pin Thermocouple
Harness Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Open
N/A
2
Red
CHT 6 (J-type thermocouple, 100404-000*)
3
Red
EGT 6 (K-type thermocouple, 100405-000*)
4
Red
CHT 5
5
Red
EGT 5
6
Red
CHT 4
7
Red
EGT 4
8
Red
CHT 3
9
Red
EGT 3
10
Red
CHT 2
11
Red
EGT 2
12
Red
CHT 1
13
Red
EGT 1
14
White
CHT 6
15
Yellow
EGT 6
16
White
CHT 5
17
Yellow
EGT 5
18
White
CHT 4
19
Yellow
EGT 4
20
White
CHT 3
21
Yellow
EGT 3
22
White
CHT 2
23
Yellow
EGT 2
24
White
CHT 1
25
Yellow
EGT 1
Table 49 – Example 9-cylinder Radial Primary SV-EMS-220 25-pin Connector Sensor Map
* Note that J-type and K-type thermocouples apply to all CHTs or EGTs, respectively. They are
not repeated in the table for brevity’s sake.
