Dynon Avionics SkyView Classic - Page 181

SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-41
SECONDARY EMS MODULE with 100399-001 Harness
Pin
EMS 25-pin Thermocouple
Harness Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Open
N/A
2
Red
Harness does not have a wire in this pin
3
Red
Harness does not have a wire in this pin
4
Red
Harness does not have a wire in this pin
5
Red
Harness does not have a wire in this pin
6
Red
Not Connected (Harness label CHT 4)
7
Red
Not Connected (Harness label EGT 4)
8
Red
CHT 9 (Harness label CHT 3)
(J-type thermocouple, 100404-000*)
9
Red
EGT 9 (Harness label EGT 3)
(K-type thermocouple, 100405-000*)
10
Red
CHT 8 (Harness label CHT 2)
11
Red
EGT 8 (Harness label EGT 2)
12
Red
CHT 7 (Harness label CHT 1)
13
Red
EGT 7 (Harness label EGT 1)
14
White
Harness does not have a wire in this pin
15
Yellow
Harness does not have a wire in this pin
16
White
Harness does not have a wire in this pin
17
Yellow
Harness does not have a wire in this pin
18
White
Not Connected (Harness label CHT 4)
19
Yellow
Not Connected (Harness label EGT 4)
20
White
CHT 9 (Harness label CHT 3)
21
Yellow
EGT 9 (Harness label EGT 3)
22
White
CHT 8 (Harness label CHT 2)
23
Yellow
EGT 8 (Harness label EGT 2)
24
White
CHT 7 (Harness label CHT 1)
25
Yellow
EGT 7 (Harness label EGT 1)
Table 50 – Example 9-cylinder Radial Primary SV-EMS-220 25-pin Connector Sensor Map
* Note that J-type and K-type thermocouples apply to all CHTs or EGTs, respectively. They are
not repeated in the table for brevity’s sake.
In Table 49 above, the Primary SV-EMS-220 uses a 100399-002 6-cylinder CHT/EGT harness;
these are connected to Cylinders 1-6.
In Table 50 above, the Secondary SV-EMS-220 uses a 100399-001 4-cylinder CHT/EGT harness;
cables marked Cylinders 1-3 are connected to Cylinders 7-9, respectively.
To configure dual EMS’ to support additional thermocouples (CHTs / EGTs), go to
SV-EMS-220, SETUP MENU > EMS SETUP > DUAL EMS SETUP:
> DUAL ENGINE MODE: NO
