SV-EMS-220/221 Installation and Configuration
7-64 SkyView System Installation Guide - Revision AA
The GRT CS-01 and CS-02 do not connect to Pin 24/25 (Amps Shunt +/- Input). If
you are converting from a Dynon Avionics EMS-D10, EMS-D120, or FlightDEK-
D180, you must change your wiring per the instructions below.
Identify the power cable for which you wish to monitor current flow. Disconnect one end and
route that cable through the CS-01/CS-02 "donut" and reconnect the cable. Note the polarity
(arrow) shown on the sensor. To monitor “Positive” current flow, the arrow should point to the
source of power (alternator, battery). If, after installation, the direction of current flow is not
(what you consider) correct, reinstall the sensor so the arrow points in the opposite direction.
Connect the three CS-01/02 wires to the SV-EMS-220/221 37-pin connector:
CS-01 / CS-02
Wire Color
EMS Harness
Wire Color
SV-EMS-220/221
Pin Number
Function
Black
Black
Any of 3, 5, 13, 16, 17, or 30
It is acceptable to share this Ground
with other sensors.
Ground
Blue
White/Red
It is
acceptable to
share this pin
/ wire with
other sensors;
see Table 32
above.
18 (+5V)
It is acceptable to share this pin / wire
with other sensors; see Table 32
above.
Power
Green
Any of Pin 8 (Brown), or
Pin 22 (Violet/Yellow), or
Pin 23 (Violet/Green), or
Pin 31 (White/Orange)
Signal
Table 61 – GRT CS-01 / CS-02 EMS Connections
The CS-01 / CS-02 have some special considerations during setup. Configure the CS-01 using the
following instructions:
 Go to SETUP MENU >EMS SETUP > SENSOR INPUT MAPPING. Choose one of Pins 8, 22, 23,
or 31, as is physically connected above.
 For the “FUNCTION” column selection, choose “AMP”
 For the “SENSOR” column selection, choose one of the AMMETER HALL EFF (offset value)
(GRT CS-01) or (GRT CS-02), where offset value is chosen per the following:
