Accessory Installation and Configuration
SkyView System Installation Guide - Revision AA 15-11
PAL S-VIDEO – Your video source is connected to the S-Video (Mini-DIN) connector and
it complies with PAL (non-US analog video standard)
FLIP HORIZONTAL: YES | NO - Select as appropriate for the image from your video input device
to display correctly on the SkyView display.
FLIP VERTICAL: YES | NO - Select as appropriate for the image from your video input device to
display correctly on the SkyView display.
Note that this menu will not be visible if no Video Input Adapter has been detected.
Checkout and Operation
To view the video input on your SkyView Classic display:
TOOLS > VIDEO
If the Video Input Adapter is connected and working, but no video signal is being
received by the Video Input Adapter, a blank blue field will be displayed for video
on the SkyView display. If you see this blue field displayed:
1. Check your connections to your video source.
2. Check that power is on to the video source.
3. Check that that the video input is correctly configured for your video device
(typically, PAL vs NTSC).
Pushing the VIDEO button repeatedly toggles the video display on and off.
Unlike the PFD, EMS, and MAP Pages, which can be displayed in various sizes,
video can only be displayed as a 100% (full screen) in SkyView Classic or 50% (split
screen) page in SkyView Classic or SkyView HDX.
To configure video to be displayed 100% or 50% page on your SkyView Classic display:
TOOLS > VIDEO (have video displayed) then
SCREEN > LAYOUT. If PFG PG, EMS PG, and MAP PG are all toggled off, video will be
displayed 100%.
To display video, push the PFD PG or EMS PG or MAP PG to display these at 50% with
video 50%.
When video is 50%, push the LAYOUT button to select whether video is display on the
left side of the display, or the right side of the display.
Note that this menu will not be visible if no Video Input Adapter has been detected. More
operational detail on using video is provided in the SkyView Pilot’s User Guide.
To view the video input on your SkyView HDX display:
DISPLAY button, then tap the VIDEO icon in the SPLIT CONTENT section.
