Accessory Installation and Configuration
15-12 SkyView System Installation Guide - Revision AA
Depending on the layout of your SkyView HDX display, the VIDEO window will appear on the
left, or right 50% window, overlaying the non-primary 50% window, or converting a 100%
window into 50% / 50% windows.
If the Video Input Adapter is connected and working, but no video signal is being
received by the Video Input Adapter, a blank blue field will be displayed for video
on the SkyView display. If you see this blue field displayed:
1. Check your connections to your video source.
2. Check that power is on to the video source.
3. Check that that the video input is correctly configured for your video device
(typically, PAL vs NTSC).
Pushing the VIDEO button repeatedly toggles the video display on and off.
Unlike the PFD, EMS, and MAP Pages, which can be displayed in various sizes,
video can only be displayed as a 100% (full screen) in SkyView Classic or 50% (split
screen) page in SkyView Classic or SkyView HDX.
To configure video to be displayed 100% or 50% page on your SkyView Classic display:
TOOLS > VIDEO (have video displayed) then
SCREEN > LAYOUT. If PFG PG, EMS PG, and MAP PG are all toggled off, video will be
displayed 100%.
To display video, push the PFD PG or EMS PG or MAP PG to display these at 50% with
video 50%.
When video is 50%, push the LAYOUT button to select whether video is display on the
left side of the display, or the right side of the display.
Note that this menu will not be visible if no Video Input Adapter has been detected. More
operational detail on using video is provided in the SkyView Pilot’s User Guide.
