Appendix E: Serial Data Output
25-8 SkyView System Installation Guide - Revision AA
Position
Width
Name
Pin
Description
36
3
Fuel
Pressure
(PSI)
Varies
000 to 999 or XXX. Fuel pressure in 1/10
th
PSI. 274 = 27.4 PSI.
There must be a pressure sensor named
“FUEL” for this to work. See note 2.
39
3
Fuel Level L
(gal)
Varies
000 to 999 or XXX. Fuel level in 1/10
th
Gallons. 128 = 12.8 Gallons.
There must be a Level sensor named
“LEFT” for this to work. If there is no
“LEFT” OR “RIGHT” but there is a “MAIN”,
this will be MAIN. See note 2.
42
3
Fuel Level R
(gal)
Varies
000 to 999 or XXX. Fuel level in 1/10
th
Gallons. 128 = 12.8 Gallons.
There must be a Level sensor named
“RIGHT” for this to work. See note 2.
45
3
Fuel
Remaining
(gal)
Fuel
Computer
000 to 999 or XXX. Fuel level in 1/10
th
Gallons. This is derived from the fuel
computer and is based on the fuel on
board added set by the user and the
decremented by fuel flow. See note 2.
48
3
Volts 1
C37 P1
000 to 360 in 1/10
th
Volts. 284 = 28.4
volts. See note 2.
51
3
Volts 2
C37 P2
000 to 360 in 1/10
th
Volts. 284 = 28.4
volts. See note 2.
54
4
Amps
C37 P24/25
+/- then 000 to 999. 1/10
th
Amps. -083 = -
8.3A. See note 2.
58
5
Hobbs Time
Calculated
00000 to 99999. In 1/10 hours. 12345 =
1234.5 hours.
63
5
Tach Time
Calculated
00000 to 99999. In 1/10 hours. 12345 =
1234.5 hours.
68
4
Thermocou
ple 1 (deg C)
C25 P2/14
+/- then 000 to 999. In degrees C. See
note 2.
72
4
Thermocou
ple 2 (deg C)
C25 P3/15
+/- then 000 to 999. In degrees C. See
note 2.
76
4
Thermocou
ple 3 (deg C)
C25 P4/16
+/- then 000 to 999. In degrees C. See
note 2.
80
4
Thermocou
ple 4 (deg C)
C25 P5/17
+/- then 000 to 999. In degrees C. See
note 2.
84
4
Thermocou
ple 5 (deg C)
C25 P6/18
+/- then 000 to 999. In degrees C. See
note 2.
88
4
Thermocou
ple 6 (deg C)
C25 P7/19
+/- then 000 to 999. In degrees C. See
note 2.
