Appendix E: Serial Data Output
SkyView System Installation Guide - Revision AA 25-9
Position
Width
Name
Pin
Description
92
4
Thermocou
ple 7 (deg C)
C25 P8/20
+/- then 000 to 999. In degrees C. See
note 2.
96
4
Thermocou
ple 8 (deg C)
C25 P9/21
+/- then 000 to 999. In degrees C. See
note 2.
100
4
Thermocou
ple 9 (deg C)
C25 P10/22
+/- then 000 to 999. In degrees C. See
note 2.
104
4
Thermocou
ple 10 (deg
C)
C25 P11/23
+/- then 000 to 999. In degrees C. See
note 2.
108
4
Thermocou
ple 11 (deg
C)
C25 P12/24
+/- then 000 to 999. In degrees C. See
note 2.
112
4
Thermocou
ple 12 (deg
C)
C25 P13/25
+/- then 000 to 999. In degrees C. See
note 2.
116
4
Thermocou
ple 13 (deg
C)
C37 P27/28
+/- then 000 to 999. In degrees C. See
note 2.
120
4
Thermocou
ple 14 (deg
C)
C37 P36/37
+/- then 000 to 999. In degrees C. See
note 2.
124
6
GP Input 1
C37 P4
+/- then 0000 to 9999, then units. See
notes.
Example: +1234C = 123.4 degrees C.
130
6
GP Input 2
C37 P22
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
136
6
GP Input 3
C37 P23
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
142
6
GP Input 4
C37 P8
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
148
6
GP Input 5
C37 P9
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
154
6
GP Input 6
C37 P10
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
160
6
GP Input 7
C37 P11
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
166
6
GP Input 8
C37 P12
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
172
6
GP Input 9
C37 P20
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
178
6
GP Input 10
C37 P21
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
