Appendix E: Serial Data Output
25-10 SkyView System Installation Guide - Revision AA
Position
Width
Name
Pin
Description
184
6
GP Input 11
C37 P6
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
190
6
GP Input 12
C37 P7
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
196
6
GP Input 13
C37 P31
+/- then 0000 to 9999, then units. +YYYYZ.
See note 3.
202
16
Contacts
Not used in
SkyView
Z*16 (ZZZZZZZZZZZZZZZZ).
218
3
Percent
Power
000 to 199 in percentage of engine
reference power. XXX when not
determined or invalid.
221
1
EGT Leaning
State
The state of EGT leaning. L: Lean of peak,
P: Peak, R: Rich of peak. X when not
determined or invalid.
222
2
Checksum
The 1 byte sum of all 217 preceding bytes.
In 25-10sci-hexformat, so 3A = 0x3A.
224
2
CR/LF
Carriage Return, Linefeed = 0x0D, 0x0A.
Table 127 – SkyView EMS Serial Output Format
Note 1: These sensors can be connected to various pins on the EMS D37M connector. See the
SkyView Installation Guide for more information.
Note 2: If the value is invalid, or out of range for the sensor, or the sensor is not configured, or
if the sensor is configured but not calibrated, then an 'X' is output for each character in the field
instead of a value.
Note 3: Units for each GP input depends on the type of sensor that is connected to the pin. See
GP Inputs
Rotax 912 iS Note: When the engine type is 912iS, the following fields in the serial output
source their data from the 912 iS’ computer instead of conventional sensors: Oil Pressure, Oil
Temp, RPM L, RPM R, Manifold Pressure, Fuel Flow 1, Fuel Flow 2 (always 0).
GP Inputs
The output for GP input pins is:
 Each output is in the format +YYYYZ
o + is the +/- sign for the value
o YYYY is the value of the signal
o Z is the units for the signal
 C if the signal is in temperature, and the units are 1/10th degrees C
 YYYY is 1/10th degrees C, so 1234 = 123.4 C
 XXXX if the signal is out of range (red X on ems page)
