o New: Support for Video Input Adapter. Allows display of video via NTSC and
PAL S-video and composite connections. Note: Only compatible with
SkyView Touch and newer SkyView SV-D1000 (s/n >= 6000) and SV-D700
(s/n >= 4000) displays.
o New: Support for third party 8.33 kHz COM radios. Supported radios include
the Trig TY91/92, f.u.n.k.e. ATR833, and Garmin GTR 225 & GNC 255 radios.
Note that full TY91/92 8.33 kHz support depends on a future software
update from Trig.
o New: Virtual-DME (non-certified) distance to VORs via GPS when the VOR
identifier is known. Magenta distance is displayed on HSI info area on PFD.
o New: SHOW AIRSPACES WITHIN XXXX FT option to declutter airspaces that
aren’t a factor at the current aircraft altitude.
o New: Wide field of view option for Synthetic Vision under PFD > MODE >
WIDE. Setting also proportionately scales the pitch ladder.
o New: Vne can now be set as TAS for aircraft that have flutter or other TAS-
dependent limits.
o New: Option to turn on color-coded weather “dots” at airports with
METARS via MAP MENU > WEATHER OPTIONS > METAR ICONS (SV-ADSB-
470 required).
o New: BARO will now sync to either the nearest METAR (when ADS-B is
available in-flight), to 29.92 (when at/above 18k feet or no ADS-B on board),
or to make the altimeter match GPS altitude (when on the ground).
o Added: Tune LOC/ILS frequencies (VORs already previously supported) on
supported NAV radios via SkyView database lookup. LOC/ILS frequencies
only available via Dynon Avionics and Jeppesen (coming soon) Databases.
o Added: Alerts are now recorded in the user datalog. These are in a new file -
ALERT_DATA.csv - so to not affect compatibility with 3rd party utilities that
can utilize SkyView datalogs.
o Added: Alert when EMS sensor definition files do not match across multiple
displays in a SkyView system.
o Added: Traffic can now be displayed on SkyView when a non-Dynon
Avionics ADS-B OUT transponder is installed in the aircraft. Such
transponders must comply with TSO C166b or later of the ADS-B spec to
allow traffic to be displayed properly.
o Added: Setup option to display or suppress tail numbers of other ADS-B
equipped aircraft (requires SV-ADSB-470).
o Added: Caution alert if transponder hex code is not set.
o Added: Option to alert the pilot when the current BARO setting and the
nearest METAR-based altimeter setting are significantly different (requires
SV-ADSB-470).
o Added: Audible “AUTOPILOT” callout when the autopilot is engaged.
o Added: Support for CAN-based MWFly engine via SV-EMS-221
o Added: Alerts when SV-AP-PANEL, SV-KNOB-PANEL go offline.
o Added: Alert when an external Level button is connected and detected
stuck at boot.
o Added: Ability to suppress the units (F, PSI, etc.) on EMS widgets via EMS
SETUP > SENSOR SETUP > [individual sensor settings]
o Added: GPS-based distances to bearing sources in HSI info area (when only
one bearing source is displayed).
o Added: Alert for detectable audio subsystem failures.
o Added: MAP MENU > FLIGHT PLAN OPTIONS > PLAN GROUND SPEED lets
SkyView perform ETE, ETA, and other speed-dependent calculations at a
user-specified ground speed when not flying.
o Added: Support for South African SRA and other rare airspaces. Part of MAP
ITEMS > UNKNOWN ALERT AIRSPACES category.
o Improved: Autopilot speed limits will not allow engagement or operation
above 95% of Vne when Vne is expressed as TAS.
o Improved: Traffic service/device reception quality indicator on map page.
o Improved: MAP MENU > MAP ITEMS > SHOW AIRSPACES BELOW changed
to HIDE AIRSPACES ABOVE for clarity.
o Improved: Autopilot trim-up and trim-down sensing and annunciation.
o Improved: Additional failure detection and annunciation of rate sensors,
accelerometers, and pressure transducers in the SV-ADAHRS-20X upon
boot.
