Appendix J: Checklists
SkyView System Installation Guide - Revision AA 30-3
Then, follow steps 13-18 as illustrated in Figure 234 at right
(step 12 and step 19 not shown):
12. On the TextEdit menu bar, click File, then Save.
13. Fill in Save As: with your checklist filename.
14. Ignore Tags:
15. Select the name of your USB flash drive (this is where
you will save your Checklist file); example: DYNON
AVIONICS or KINGSTON:
o (older versions of Mac OS) Change Where: to the name of your USB flash drive.
o (newer versions of Mac OS, Where: will not be shown) In the left column of the
Finder, under Devices, click on (the name of) your USB flash drive.
16. Ensure Plain Text Encoding: is set to Unicode (UTF-8).
17. Ensure the box for If no extension is provided, use “.txt” is checked.
18. Click the Save button.
19. In the left column of the Finder, next to the name of your USB flash drive, click on the
“Eject button” to close all files on your USB flash drive before physically removing the
USB flash drive from your Mac.
Windows Notepad
To save a Checklist file in Windows Notepad using “UTF-8 Character Encoding, follow these
steps:
1. Click on File.
2. Click on Save As…
3. On the left side of the window, click on the drive letter of the USB flash drive. This will
ensure that the Checklist file will be saved to the USB flash drive. Example: Drive F: (but
your computer may assign a different drive letter).
4. File Name: (fill in your preferred filename for your Checklist file).
5. Save as type: Text Documents (*.txt).
6. Encoding: Pull down and select UTF-8.
7. Click the Save button.
Steps 4-7 are illustrated in Figure 233 below.
Figure 233 – Windows Notepad Save As with UTF-8 Encoding
There can only be one Checklist file loaded in a SkyView system at a time. It is not possible to
have different Checklist files loaded onto different SkyView displays in a single SkyView system,
