SkyView Display Installation and Configuration
4-24 SkyView System Installation Guide - Revision AA
connected to these devices in SERIAL PORT x SETUP, SERIAL IN DEVICE to GARMIN TIS
TRAFFIC (which will automatically set the associated parameters).
If a device that can provide traffic data is connected to SkyView and configured (usually as a TIS
serial traffic device under SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP), further traffic
display options can be configured in SETUP MENU > TRAFFIC SETUP. Display of traffic on the
MAP page and the PFD page can be set to:
NONE (Do not display traffic)
TA ONLY (Display only Traffic Advisories [TAs])
ALL (Display ALL traffic)
Only one device can provide traffic information to SkyView at any moment. If you
have more than one device connected to SkyView that is capable of providing
traffic (such as, but not limited to, SV-XPNDR-261/262 (TIS), SV-ADSB-470, Zaon
XRX, etc.), the devices provide traffic information with the following priority,
based on the completeness of the traffic portrait they provide:
1. SV-ADSB-470 with full traffic (ADS-B ground station reporting with radar
coverage)
2. TIS transponder from SV-XPNDR-261/262 or Garmin GTX 330 / ES (when in an
active TIS coverage area)
3. FLARM
4. Zaon
5. SV-ADSB-470 with No RADAR (ADS-B reception, but without ground ADS-B
station coverage or radar target inclusion).
Dynon Avionics SV-XPNDR-261/262 Transponder
See the SV-XPNDR-261/262 Installation and Configuration section for detailed instructions on
how to set up the serial connection to the SV-XPNDR-261/262.
Note that if you are using a Dynon Avionics SV-XPNDR-261/262 Transponder, none of the
encoder options in the below sections should to be set for the Dynon Avionics SV-XPNDR-
261/262 module to receive pressure altitude. Instead, when the SV-XPNDR-261/262 is set up as
described in the SV-XPNDR-261/262 Installation and Configuration section, it is automatically
configured to receive pressure altitude from SkyView. Alternatively, systems that require the
use of an external altitude encoder can be configured per the following section to have SkyView
pass along an external pressure altitude source.
Dynon Avionics SV-ADSB-470
See Section 14 - SV-ADSB-470 Installation and Configuration for detailed instructions on how to
set up the serial connection to the SV-ADSB-470.
Garmin GTX 330ES
To enable ADS-B traffic with a Garmin GTX 330ES, both the serial port transmit and serial port
receive between SkyView and the GTX 330ES must be connected and configured. The GTX
330ES must be fully configured to output ADS-B Out, which requires a TSO’d GPS position.
