Dynon SkyView HDX - Page 160

SV-EMS-220 Engine Monitoring System Installation and Configuration
10-32 SkyView HDX System Installation Manual - Revision E
o NAME CLOSED
o COLOR GREEN
o TOP 2.5 VOLTS
o BOTTOM 0.0 VOLTS
• RANGE 3
o ENABLE NO
o NAME R3
o COLOR GREEN
o TOP 20.0 VOLTS
o BOTTOM 10.0 VOLTS
• RANGE 4
o ENABLE NO
o NAME R4
o COLOR YELLOW
o TOP 10.0 VOLTS
o BOTTOM 5.0 VOLTS
• RANGE 5
o ENABLE NO
10.7.6 Example RPM Setup
Assume this sensor was mapped on the Sensor Input Mapping Wizard as:
Table 23: Example Sensor Input Mapping for C37 P32/34 (RPM / Tachometer)
PIN #
FUNCTION
SENSOR
NAME
C37
P32/34
RPM
RPM
RPM
Now, we want to configure its alert and graphical properties. Go to the Sensor Setup
Menu and open the RPM Page (SETUP MENU > EMS SETUP > SENSOR SETUP >
RPM RPM).
Configure RPM with the following properties:
• ALARM: OFF
• MAXIMUM GRAPHICAL DISPLAY:3000 RPM
