System Overview
2-16 SkyView HDX System Installation Manual - Revision E
Unit
Dimensions
Weight
SV-BAT-320
3.30” W x 2.10” H x 3.90” D
(84mm W x 53mm H x 99mm D)
0.80 lb. (0.40 kg)
SV-EMS-220
6.35” W x 1.09” H x 2.99” D
(161mm W x 28mm H x 76mm D)
0.63 lb. (0.29 kg)
SV-GPS-2020
2.19” W x 0.75” H x 3.44” D
(56mm W x 19mm H x 87mm D)
0.44 lb. (0.20 kg)
0.47 lb. (0.21 kg)
SV-HDX800
7.64” W 5.59” H x 3.21” D
(194mm W x 142mm H x 82mm D)
2.75 lb. (1.25 kg)
SV-HDX1100
10.31” W x 7.1” H x 3.1” D
(262mm W x 180mm x 79mm D)
3.35 lb. (1.52 kg)
SV-KNOB-PANEL
3.53” x 1.80” x 1.27” D
(89.7mm x 45.7mm H x 32.4mm D)
0.40 lb. (0.18 kg)
SV-MAG-236
4.71” W x 1.22” H x 2.61” D
(120mm W x 31mm H x 66mm D) (not
including cable - 18” (457mm)
0.46 lb. (0.21 kg)
SV-XPNDR-261
(w/mounting tray)
2.5” W x 1.9”H x 6.3” D
(66mm W x 48mm H x 160mm D)
0.77 lb. (0.35 kg)
Table 6 contains environmental specifications for major SkyView units.
Table 6: SkyView System Component Environmental Specifications
Environmental Specifications
Storage Temperature
Operating Temperature
SV32 (various)
SV42 (various)
-22° F to 167° F
(-30° C to 75° C)
-22° F to 140° F
(-30° C to 60° C)
SV-ADAHRS-200
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-ADSB-472
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to +60° C)
SV-ARINC-429
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to +60° C)
SV-BAT-320
-4° F to 140° F
(-20° C to 60 °C)
-4° F to 140° F
(-20° C to 60° C)
SV-HDX800
SV-HDX1100
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-EMS-220
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-GPS-2020
-40° F to 158° F
(-40° C to 70° C)
-40° F to 140° F
-40° C to 60° C
SV-KNOB-PANEL
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-MAG-236
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-XPNDR-261
-67° F to 185° F
(-55° C to 85° C)
-4° F to 158° F
(-20° C to 70° C)
