206
Solution Ultima 844/862/880 Installation Manual
1 Sirens Running
This output will operate for the duration of the siren run time programmed in "LOCATION
423" on page 219. When the sirens have been activated, this output will reset once the
siren run time has expired. The relay output (Output 4) is factory default for this operation.
20 Strobe Operating
This output will operate when an alarm condition occurs and will reset once a valid user
code has been entered. The strobe output (Output 3) is factory default for this operation
and is programmed to automatically reset after 8 hours of duration.
21 Silent Alarm
This output will operate when any zone programmed to be silent alarm has triggered. The
output will reset when the siren run time expires, an audible alarm has triggered, or a valid
user code has been entered. Refer to Zone Options 1 on page 175 to program zones to be
silent.
22 Alarm When In STAY Mode
This output will operate whenever an audible or silent zone alarm has triggered when the
system has been armed in STAY Mode 1 or STAY Mode 2. The output will reset when the
system has been disarmed.
23 Alarm When In AWAY Mode
This output will operate whenever an audible or silent zone alarm has triggered when the
system has been armed in AWAY Mode. The output will reset when the system has been
disarmed.
24 Mimic System Fault
This output will operate without any time delays as soon as any system fault occurs
including if the AC mains supply has failed. The output will reset as soon as the system
fault or the AC mains supply has restored.
25 Fire Alarm Resetting
This output will operate when a 24-hour fire zone is triggered. The output will reset once a
valid user code has been entered or when siren run time expires. If the control panel has
been partitioned, a user code allocated to another area may reset this output.
26 Fire Alarm Latching
This output will operate when a 24-hour fire zone has triggered and will reset when the
system has been armed or disarmed. If the system has been partitioned, the output will
reset when any area has been armed or disarmed.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
