208
Solution Ultima 844/862/880 Installation Manual
2 Radio Control Output 2 – Not In AWAY Mode
This output will operate when you hold down button 4 on the 4-channel hand held
Transmitter only when the system is disarmed or armed in STAY Mode 1 or STAY Mode
2. The output will not operate when the system is armed in AWAY Mode. If you enable
option 8 in LOCATION 436 on page 227, this output will not operate and will only arm the
system in STAY Mode 1.
2 Communications Failure After 3 Unsuccessful Calls
This output will operate when the communication dialler has made 3 unsuccessful calls to
the base station receiver. The output will reset when all messages have been sent (i.e..
When the buffer is empty or when all possible attempts have been made).
30 Communications Failure
This output will operate when the communication dialler has made all possible attempts to
reach the base station receiver. The output will reset when the first "Kiss-Off" has been
received. This output will not operate for domestic formats.
31 Dialler Disabled
This output will operate as long as Option 1 in "LOCATION 177" on page 153 has been
disabled. The output will reset once Option 1 – Enable Dialler Reporting Functions in
"LOCATION 177" on page 153 has been enabled.
32 Dialler Active
This output will operate when the communication dialler is on-line. The output will reset
when the communication dialler has released the telephone line.
33 Ring Detect
This output will operate when an incoming call has been detected by the control panel. The
output will reset when the ringing has stopped or when the call has been answered.
34 Codepad Panic (Multi-Break)
(V1.05 +) This output will operate when a panic alarm has been initiated via the codepad.
The output will operate for 200 ms if you program the polarity as one (1). However, you
can program the time base and multiplier to increase the duration that the output will
operate.
35 Mimic Zone 1 39 Mimic Zone 5
36 Mimic Zone 2 3 Mimic Zone 6
37 Mimic Zone 3 3 Mimic Zone 7
38 Mimic Zone 4 3 Mimic Zone 8
These output types will mimic the zone inputs. The output will operate when the zone is
unsealed and will reset when the zone has resealed. They will operate regardless of the
zone type chosen (i.e.. A zone "Not Used" can still operate a mimic output). This feature
operates when the system is armed or disarmed.
45 Global Chime
This output will operate when any zones programmed as "Chime" have triggered. The
output will reset when the zone has resealed. Refer to Zone Type on page 169 for more
information.
46 Zone Not Sealed
This output will operate whenever a burglary zone is unsealed. Chime zones will not
operate this output event type.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
