EDM Solution Ultima 844 - Page 293

Location 440 Page 231
Consumer Options 1
Location 441 Page 232
Consumer Options 2
Location 442
Page 233
Consumer Options 3
Location 443
Page 234
Radio Input Options
Location 478 – 525 Page 127
Domestic Telephone Numbers
Location 526
Reserved
Location 527 Page 250
RF Options
Location 528 – 535 Page 250
RF Device Mapping (Devices 1 – 8)
Location 536 – 543 Page 250
RF Device Mapping (Devices 9 – 16)
Location 801 – 808 Page 251
RF Device Signal Strength (Devices 1 – 8 Read Only)
Location 809 – 816 Page 251
RF Device Signal Strength (Devices 9 – 16 Read Only)
Location 900 Page 118
Disable Factory Default
Location 901 – 904 Page 222
System Time
Location 905 – 910 Page 223
System Date
1 = Test Reports Only When Armed
2 = Test Report After Siren Reset
4 = Auto Arm In STAY Mode 1
8 = STAY Indicator To Display Day Alarm Status
0
1 = Codepad Display Extinguish After 60 Seconds
2 = Single Button Arming Allowed (AWAY Mode, STAY Mode 1 & 2)
4 = Single Button Disarming Allowed (STAY Mode 1 & 2)
8 = Alarm Memory Reset On Disarm
2
5
1 = Codepad Fault Alarm Beeps Allowed
2 = Use Digit 3 For Codepad Duress Instead Of Digit 9
4 = Alarms Activate Siren & Strobe In STAY Mode 1 and STAY Mode 2
8 = Zone Tamper Alarms To Be Silent
1 = DS 304 MHz Receiver (RF3212)
2 = Latching Keyswitch Input
3 = Momentary Keyswitch Input
4 = Reserved
0
0
0
1 = Sound Siren On RF Receiver Fail
2 = Sound Siren On RF Receiver Tamper / Jamming
4 = Unseal Zone That Fails Supervision (Only If Supervision Enabled)
8 = Enable RF Jamming Monitoring
1 3 6 7 8
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 = Defaulting Enabled
15 = Defaulting Disabled
0
Location 901 Hour Of The Day (Tens Digit)
Location 902 Hour Of The Day (Units Digit)
Location 903 Minute Of The Day (Tens Digit)
Location 904 Minute Of The Day (Units Digit)
0000
0 10101
Location 905 Day Of The Month (Tens Digit)
Location 906 Day Of The Month (Units Digit)
Location 907 Month Of The Year (Tens Digit)
Location 908 Month Of The Year (Units Digit)
Location 909 Year (Tens Digit)
Location 910 Year (Units Digit)
Solution Ultima 862
Programming Sheets 293
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
2 54
0 00
0 00
0 00
