FOR-A HVS-XT100 User Manual

116
 PC Requirements and Network Settings
An Ethernet port (100BASE-TX/1000BASE-T) and FTP client function are required for the
personal computer. Any type of computer or OS can be used. In this section a Windows XP or
7-installed PC is used as an example.
Network Setting
IP Address
192. 168.0.10 (default)
Main unit
Subnet mask
255. 255. 255.0(default)
IP Address
192. 168.0.1 to 192. 168.0.254
(Do not set the same IP as the main unit)
Computer
Subnet mask
255. 255. 255.0
Refer to the procedure below to open the setting dialog and change the computer network
settings, if necessary.
<Setting the IP Address in Windows XP>
Go to Start > My Network Places. Right-click My Network Places, and choose Properties.
Right-click the Local Area Connection icon and choose Properties. Select the Internet
Protocol (TCP/IP) check box, and click Properties.
<Setting the IP Address in Windows 7>
Go to Start >> Control Panel >> Network and Internet >> Network and Sharing Center,
and then click Change adapter settings. Right-click the Local Area Connection icon and
choose Properties. Click the Internet Protocol Version 4(TCP/IPv4) check box, and click
Properties.
NOTE
The setting example above is for connecting the computer and switcher. Although the
IP address of the switcher can be changed, the computer IP address should normally
be changed.
 See section12-4-1. "LAN Connection" for network settings in the switcher.
12-4-2. Image files
Image File Format: JPEG, TARGA and BITMAP (See the table below.)
Image Size: Less than 1920 x 1080 [pixels]
File Name Format: (any file name).jpg, (any file name).tga and (any file name).bmp
Use the three-letter extension after the period. Any length of any
characters can be used for file names.
File Format
Description
Limitation (unavailable data)
JPG
JPEG Compression data
Grey-scale image data
TGA
TARGA data
RLE compression data
BMP
BITMAP data
RLE compression data
