12-4-4. Sending Images to Clip Memory
 Preparation
(1) Prepare sequential image files in the following name format.
File name: [STILLXXX.yyy]
XXX:
Indicates Serial numbers.
000 to 226
(1080/59.94i, 29.97PsF)
000 to 219
(1080/50i, 25PsF, 24PsF, 23.98PsF)
000 to 498
(720/59.94p, 50p)
000 to 998
(NTSC, PAL)
yyy:
Indicates a file extension. bmp, jpg or tga.
WARNING: "STILL" must be in upper case.
(2) Connect to the PC, referring to steps (1) to (7) in the previous page.
 Uploading Sequential Images to Clip Memory in the switcher
(1) Open the folder on the PC, in which sequential files are stored.
(2) Drag and drop all sequential files to be uploaded to a clip folder (CLIP1 or CLIP2) on the
FTP server. Sixty image files of data can be transferred in about 3 minutes.
