21-12. MATTE
Click MATTE in the HOME screen to display the MATTE menu page.
 See section 5-9. "Bus Matte"
To Specify Color for MATT1 and MATT2
 See section 5-9-1. "Setting the Matte Color."
Select color by setting the HSL values, by selecting a preset color under RECALL or using the
color circle. To set color on the color circle, specify Hue in the outer circle and Luminance and
Saturation on the inner rectangle.
To Specify Gradient Matte (MATT2 only)
 See section5-9-2. "Setting the Gradient Matte."
(1) Select a start color for the gradadient matte under COLOR1.
(2) Select an end color for the gradadient matte under COLOR2.
(3) Select a pattern for the gradation matte under PATTERN.
(4) Set the position at POSITION and adjust the softness gradient at SOFT.
