22-1-3. HVS-XT110
Video Formats
1080/59.94i, 1080/50i,
1080/24PsF, 1080/23.98PsF, 1080/25PsF, 1080/29.97PsF,
720/59.94p,720/50p
525/60 (NTSC), 625/50 (PAL)
Video Input
HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75Ω BNC x 12
Video Output
HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps
75Ω BNC x 8 (AUX1-AUX8. Crossface switching available)
HDMI:
HDTV (1080i, 720p ) SDTV (SD)
HDCP unsupported
HDMI type A connector x 1
Genlock Input
BB: NTSC: 0.429 Vp-p/PAL: 0.45Vp-p or Tri-level Sync: 0.6 Vp-p
75Ω BNC x 1, loop-through (Terminate with 75Ω terminator, if unused.)
System Phase Adjust
Horizontal: -1/2H to +1/2H
Genlock Output
BB: NTSC: 0.429 Vp-p/PAL: 0.45Vp-p or Tri-level Sync: 0.6 Vp-p
75Ω BNC x 1
Signal Processing
4:2:2 Digital component
Quantization
HD/SD-SDI: 10-bit
FS / Process Amp
Frame Synchronizer feature on INPUT01-08
Process Amp feature on each input
Effect
Pattern
WIPE
100 patterns, Border and Softness
2D DVE
36 patterns
Sub-effect
channel
x 2 (SBEF1 and SBEF2) available on inputs
Transition
Execution: Fader lever, AUTO or CUT button
Type: MIX or WIPE (DVE included)
Still/Clip Memory
2 still buffers with backup feature
2 clip buffers, Recording capacity: 7.5 seconds (HD video)for each
Key
KEY/DSK
x 4 (KEY x 2 and DSK x 2)
Luminance, Full or Bus key,
KEY1, KEY2: Edge/shadow effects
DSK1, DSK2: Direct display on AUX outputs possible
Chroma key
channel
x 1 (used for switcher source / direct output)
DVE channel
x 4 (2D) Available on BKGD, KEY and DSK
Multiviewer channel
x 1 with 2/4/5/7/9/10/11/16-way split views
Display: Title, Tally, Audio Level Meter, Safety Area and Frame Border
Layout backup: Up to 8 patterns
1 frame delay relative to PGM output
Event Memory
100 events
I/O Delay
Minimum delay:
HD: 1H, SD: 1H
If FS or Up-resize engine used:
1-2 frames + Minimum delay
If FS or Up-resuze engine plus DVE
used:
2-3 frames + Minimum delay
FS or Up-resize engine plus Output
resize engine and DVE used:
3-4 frames + Minimum delay
