FOR-A HVS-XT100 User Manual

48
6-2. Preview Set Up
The switcher does not have a dedicated PREVIEW output. A preview bus output can be
assigned to, however, an AUX output. Users can also add key images to PREVIEW. This can be
done as explained below:
6-2-1. Preview Bus Monitoring
Follow the procedure below to assign a preview video to an AUX output. AUX1 is used in the
example below.
(1) Double-press AUX1 on the left side of the control panel to display the [SETUP - OUTPUT
- OUT XPT] (1/3) menu.
(2) Turn F1 to select AUX1.
(3) Turn F2 to select PVW.
OUTPUT :SELECT : XPT : TRANS RATE : 1/3
OUT XPT : =AUX1 : =PVW :En=OFF =0 :
6-2-2. Setting Up Preview Images
(1) Double-press PREV to display the [SETUP - OUTPUT - CLN/PREV] (2/2) menu.
(2) Turn F1 to F4 to set whether the key images are to be displayed on the preview image,
then press the push-button to confirm the setting for each.
OUTPUT : KEY1 : KEY2 : DSK1 : DSK2 : 2/2
M/E PRV : =ON : =ON : =OFF : =OFF :
KEY1-2
Parameter
Setting
NEXT TRANSITION
KEY
On-Air/Off-Air
KEY1-2 on
PREVIEW images
PREVIEW OUT -
KEY1
ON
KEY1 button ON
On-Air
Not displayed
ON
KEY1 button OFF
On-Air
Displayed
PREVIEW OUT -
KEY2
ON
KEY2 button ON
Off-Air
Displayed
ON
KEY2 button OFF
Off-Air
Not displayed
PREVIEW OUT -
KEY1-2
OFF
---
---
Not displayed
Whether KEY images are displayed on the preview depends on both the PREVIEW OUT settings and KEY
button status in the NEXT Transition block.
DSK 1-2
Parameter
Setting
DSK1-2 on
PREVIEW images
PREVIEW OUT - DSK1
PREVIEW OUT - DSK2
ON
Displayed
OFF
Not displayed
