79
8-11-3. Transition Limit
The Transition Limit setting determines how far your transition can proceed. When
performing transitions (mix or other) there may be times when you want the transition to the
next signal to only complete to a certain degree instead of fully switching from one picture to
another.
To perform background transitions that do not fully switch pictures, proceed as follows.
(2) Turn F2 to set to 90.0. Turn F3 to set to ON under TRANS LIMIT.
TRANS : RATE :TRANS LIMIT :PAT NO : 1/6
BKGD : =30 :=90.0 =ON : =0 :
(3) Let's perform background MIX or WIPE transitions by pressing AUTO or moving the fader
lever. The transition must be completed before the background pictures are fully switched.
The default settings are 100.0 and OFF. With this setting, the transition is complete with fully
switching pictures.
In the following menu pages, the transition limit for KEY1-2 and DSK1-2 can be set in the
same way
8-11-4. Adjusting the Fader Offset
The fader offset range can also be adjusted in the [SETUP - PANEL - TRS CTRL] menu. Turn
F3 and F4 to adjust the fader OFFSET.
PANEL :BUSTYPE: : FADER OFFSET : 1/1
M/E CTRL: =P/P : :U=1.00 L=1.00 :
Sets the upper edge offset.
Sets the bottom edge offset.
8-11-5. Endpoint Processing for DVE Transitions
In DVE operations, differences in video delay times when entering and exiting DVE effects
can cause the video to appear choppy. This choppiness can be reduced by menu setting so
that the DVE effect always exits at the transition start and end points (TRS EDGE to OFF in
the [SETUP - FUNCTION - M/E_KEY] menu).
FUNCTION:TRSEDGE:KEY LNK: DSK ASSIGN : 1/1
M/E KEY : =OFF : =ON :1=M/E 2=M/E :
