18-6. Status Information
The STATUS menu indicates current cooling fan, power and genlock status and the versions of
hardware and software.
18-6-1. Checking Alarm Status
(1) Open the [SETUP - STATUS] menu. Turn F1 to select ALARM, then press F1 or the page
down button to display the submenu.
SETUP :>ALARM >VERSION >OPTION
STATUS :
(2) The STATUS submenus display the current status of the cooling fan, power and genlock
as shown below.
 HVS-XT100
STATUS :FAN1: NOR 2: NOR : 1/3
MU ALARM: PS1: NOR 2: NOR :
STATUS : GENLOCK:External Lock : 2/3
MU ALARM: :
STATUS : PS1: NOR 2: NOR : 3/3
OU ALARM: :
Item
Display
Description
FAN1-2
(MU)
NOR
Indicates FANs are working properly.
ERR
Indicates a FAN has failed. Power off the switcher and
consult your FOR-A reseller.
GENLOCK
External Lock
Indicates a valid reference signal is present and video
signals are properly locked to the reference signal.
Internal Lock
Indicates the internal reference is being used, and as
such, either the absence of external reference signal, its
level is too low, or the presence of a reference in a
different format.
PS1-2
(MU, OU)
NOR
Indicates Power Supply Units are working properly.
---
Indicates no power supply. (OU only)
ERR
Indicates a Power Supply Unit has failed. Power off the
switcher and consult your FOR-A reseller. (MU only)
 HVS-XT110
STATUS :FAN1: NOR FAN2: NOR FAN3: NOR : 1/2
MU ALARM: :
STATUS : GENLOCK:External Lock : 2/2
MU ALARM: :
Item
Display
Description
FAN1-3
NOR
(see the table above.)
ERR
GENLOCK
External Lock
