8-9. Modifying Patterns
Preset patterns can be modified using the WIPE menu. Two pattern types are available: WIPE
and DVE. Each type has its own menu pages.
Pattern No.
Type of Group
Available modification settings
0 to 99
WIPE
2D border, multi, 2D position, 2D size, etc.
100 to 137
DVE (2D DVE)
2D border, 2D position, 2D size, crop, etc.
If a pattern is modified, the pattern number starts with the letter "M" in the [TRANS](1/6) menu as
shown below.
TRANS : RATE :TRANS LIMIT :PAT NO : 1/6
BKGD : =30 :=100.0 =OFF : =M0 :
The following chapters explain how to modify patterns using the background and KEY1 as
examples.
8-9-1. WIPE Type (No. 0-99)
 WIPE menu
The pattern number is displayed instead of "0XX" in the top page of the submenu.
WIPE :>BORDER >POS/ANGL>MULTI >CG WIPE
No.0XX :>INIT
WIPE :SIGNAL : WIDTH : SOFT : : 1/2
BORDER : =MATT : =0.0 : =0.0 : :
WIPE : BORDER COLOR :RECALL : 2/2
BORDER :S=66.3 L=5.4 H=3.5 : >WHITE:
WIPE : POSITION : ANGLE :ASPECT : 1/1
POS/ANGL:X=0 Y=0 : =0.0 : =0.0 :
WIPE : MULTI : : 1/1
MULTI :X=1 Y=1 : :
WIPE : INIT : : 1/1
INIT : >OFF : :
 See section 12-5-3. "CG WIPE Menu Quick Reference" for details on CG WIPE pages.
