FOR-A HVS-XT100 User Manual

191
21. Web-based Control
21-1. System Setup
 System Requirements
The HVS-XT100 Series web-based control feature needs a user-prepared computer, which
must meet the following system requirements.
Operation System
(tested and evaluated)
Windows XP or 7
iOS 6.1.3
Processor
Depends on the browser used.
Web browser
Google Chrome or Safari recommended (Internet Explorer is
not supported.)
RAM
Depends on the browser used.
Display
Resolution of 1024 × 768 pixels or higher
24-bit full-color
Network Port
Ethernet, at least 1 port
100BASE-TX/1000BASE-T
Network Cable
100BASE-TX: Category 5 or higher
1000BASE-T: Enhanced Category 5 or Category 6
Max. number of connection
to the switcher
3
 Computer Network Settings
To connect to the switcher, set the IP address of your computer as follows:
IP Address
192.168.0.1 to 192.168.0.254 (except 192.168.0.10)
Subnet Mask
255.255.255.0
 Connecting to the Switcher
1. Use the LAN port on the switcher to connect to the PC directly or via a network hub.
 See section 12-4-1. "LAN Connection."
2. Launch your web browser. (Chrome or Safari recommended)
3. Enter "http://192.168.0.10" (default) in the address box and connect to the switcher.
IMPORTANT
If you have changed the switcher IP address, enter the changed address.
4. The HOME screen as shown on the next page will appear.
Verify that the connection indicator in the upper right corner is lit green.
IMPORTANT
Note that web browsers cannot automatically reconnect to the switcher after the
switcher has rebooted (the connection indicator may be unlit). In such case, reconnect
to the switcher or refresh the switcher control page on the web browser to re-establish
the connection.
