74
To Register the Modified Pattern to a Direct Pattern:
 Refer to section 8-8-3. "Direct Pattern Function" to save a modified pattern to a direct
pattern.
To Reset the Modified Pattern:
(1) Press WIPE in the transition block to display the [TRANS] (1/6) menu. The letter "M"
(Modified) will be displayed in front of 20.
TRANS : RATE :TRANS LIMIT :PAT NO : 1/6
BKGD : =30 :=100.0 =OFF := M20 :
(2) Press and hold down F4. Pattern 20 will be reset to its default settings.
8-9-2. DVE Type (No. 100-137)
 WIPE menu
The pattern number is displayed instead of "1XX" in the top page of the submenu.
WIPE :>BORDER >POS/ASP >CROP >CG WIPE
No.1XX :>INIT
WIPE : INSIDE : OUTSIDE : 1/3
BORDER :X=0 Y=0 :X=0 Y=0 :
WIPE : INSIDE :OUTSIDE: : 2/3
BDR SOFT:X=0 Y=0 : =0 : :
WIPE : BORDER COLOR :RECALL : 3/3
BDR COL :S=0.0 L=100.0 H=0.0 : >WHITE:
WIPE : POSITION : SIZE : : 1/2
POS/SIZE:X=0 Y=0 : =1000 : :
WIPE : ASPECT :FADE LV: : 2/2
ASPT/FAD:X=1000 Y=1000 : =0.0 : :
WIPE : CROP POSITION : 1/1
CROP :T=0.0 B=0.0 L=0.0 R=0.0 :
WIPE : INIT : : 1/1
INIT : >OFF : :
 See section 12-5-3 "CG WIPE Menu Quick Reference" for details on CG WIPE pages.
