42
5-7. Frame Synchronizer
A video frame synchronizer is provided respectively for IN01 to IN08 and is used to synchronize
asynchronous signals. Users can select whether to apply frame synchronization to input signals
or not (for each signal) as shown in the procedure below.
(1) Display the [SETUP - INPUT - SIGNAL] menu.
(2) Turn F1 to select an input signal for use.
(3) Turn F4 to set FS to ON and activate the frame synchronizer.
INPUT :SELECT :FORMAT :RESIZE : FS : 1/4
SIGNAL : =IN02 : =AUTO : =16:9 : =ON :
To Enable/Disable FS Using a User Button (Operation Example)
<Assigning FS ENABLE to USER 3>
(1) Open the [SETUP - PANEL - USER BUTTON] (1/2) menu.
(2) Turn F1 to select OU-3 (OU USER 3). USER 3 will blink.
(3) Turn F2 to select OTHER. Turn F3 to select FS ENABLE.
USER :SELECT : TYPE : FUNC(F3) : 1/2
BUTTON : =OU-3 : =OTHER: =FS ENABLE
<Enabling FS for IN01>
While holding down USER 3, press a KEY/AUX bus button to which IN01 is assigned. (Press 1 ,
for example, if IN01 is assigned to Bus Button 1.) The frame synchronizer function for IN01 will
be enabled.
<Disabling FS for IN01>
While holding down USER 3, press a KEY/AUX bus button to which IN01 is assigned. The
frame synchronizer function for IN01 will be disabled.
Ancillary data in input video cannot be passed through if FS (input frame synchronizer) is
set to ON or RESIZE is enabled. To pass ancillary data, input the video synchronized with
the genlock signal and set FS to OFF. Note that ancillary data in SD inputs cannot be used
when the switcher operates in HD mode.
