(2) Turn F1 to select an AUX LINK group to be set in the LINK GROUP menu (up to 20
groups).
(3) Turn F2 to select a signal to be set for MASTER
(4) To set the SLAVE output signals (up to three) that link to the MASTER output signal, press
F3 and then turn F3 to select a signal for Slave 1. Press F3 and then turn F3 to select a
signal for Slave 2. Select a signal for Slave 3 in the same way.
The same MASTER output signal cannot be selected twice. SLAVE output signals can
be selected multiple times.
6-8-3. Enabling AUX LINK
(1) Display the [SETUP - FUNCTION - AUX LINK] menu.
(2) Turn F1 to set ENABLE to ON. This activates all AUX LINK groups.
Operation examples:
Assume that the AUX output link groups and their signal link groups were set as shown
below.
:SELECT:MASTER: SLAVE SEL/AUX : 2/3
AUX GRP : =1 : =AUX1 :1=AUX2 2=AUX3 3=AUX4
: =2 : =AUX7 :1=AUX8 2=OFF 3=OFF
: =3 : =PGM :1=KEY1 2=KEY2 3=OFF
: =4 : =ME-A :1=ME-B 2=OFF 3=OFF
: =5 : =OFF :1=--- 2=--- 3=---
: ... : ... : ...
:SELECT:MASTER: SLAVE SEL/AUX : 3/3
LINK GRP: =1 : =IN01 :1=IN02 2=IN03 3=IN04
: =2 : =PGM :1=PREV 2=OFF 3=OFF
: =3 : =IN05 :1=STL1 2=STL2 3=OFF
: =4 : =IN06 :1=IN07 2=OFF 3=OFF
: =5 : =OFF :1=--- 2=--- 3=---
: ... : ... : ...
Press AUX1 in the BUS SELECT-AUX block and select IN01 on the AUX/KEY bus:
>> IN02 is assigned to AUX2, IN03 to AUX3 and IN04 to AUX4.
Press AUX7 in the BUS SELECT-AUX block and select PGM:
>> PREV is assigned to AUX8.
Select IN05 in PGM bus:
>> STL1 is assigned to KEY1-INSERT and STL2 to KEY2-INSERT.
Select IN06 in M/E- A bus:
>> IN07 is assigned to M/E-B bus
