139
15-4-3. Setting the User Default Menu when Storing an Event
The [EVENT STORE] menu appears as shown below in the factory default setting when
storing events.
EVENT :SELECT : XPT : DATA : RATE : 1/2
STORE : =ALL : =ON : =ON : =0 :P.00
EVENT :AUX SEL:AUX RCL:DSK ASG:CG WIPE: 2/2
STORE : =ALL : =OFF : =OFF : =OFF :P.00
Changing the default setting of the [EVENT STORE] menu is possible. To do this, proceed as
follows.
(1) Press EVENT in the SELECT/KEYPAD block to display the [EVENT MEMORY] menu.
(2) Change the following menu items to the desired settings, which become the default settings
in the [EVENT MEMORY] menu. (Only highlighted items are changeable.)
EVENT : PAGE :DIRECT :PAGECLR: RATE : 1/2
MEMORY : =0 : =OFF : >CRNT : =OFF : L=0
EVENT :AUX BUS: :DSK ASG:CG WIPE: 2/2
MEMORY : =OFF : : =OFF : =OFF : L=0
15-4-4. Detailed Data Selection for Loading Events
If DIRECT is OFF and while loading events, data to be loaded to the control panel can further
be narrowed down in the menu as shown below.
After pressing a number button, the [EVENT RECALL] menu is displayed. The data can be
reduced using the menu, in which the same parameters in the [EVENT STORE] menu can be
set.
See section 15-4-2. "Detailed Data Selection for Saving Events."
See "Selecting Data to be Loaded" in section 15-2. "Recalling Events" for details on how
to select load data.
