FOR-A HVS-XT100 User Manual

213
21-15-6. SETUP - FUNCTION
Click the FUNCTION tab to display and set the FUNCTION menu.
Click a button to go to the desired menu
block. See the operation manual main
pages for details on each function.
KEY/DSK
 See section 8-11-5. "Endpoint
Processing for DVE Transitions"
 See section 9-3-1. "Key Link"
 See section 8-5-1. "Where DSK
Images Appear"
AUX LINK
 See section 6-8. "AUX LINK"
21-16. STATUS
Click STATUS in the HOME screen to display the STATUS menu page.
 See section 18-6. "Status Information"
Click a button to go to the desired menu block. See the
operation manual main pages for details on each function.
ALARM
 See section 18-6-1. "Checking Alarm Status"
VERSION
 See section 18-6-2. "Verifying Versions"
OPTION
 See section 18-6-3. "Installed Options"
