185
20-3-8. Simultaneous Switching Using Take
Multiple crosspoints (destination/source pairs) can be switched simultaneously in the menu
using stored crosspoint data.
Setting Crosspoints
(1) Go to PAGE 3 in the [SETUP - EXT I/F - ROUTER] menu.
(2) Turn F1 to select a level.
(3) Turn F2 to select a destination. If a source to be paired has been set, the source channel
number is displayed. DEST1 and SRC1 are paired in the menu example below.
EXT I/F : LEVEL : DEST : SRC : TAKE : 3/6
ROUTER : =1 : =1 : =1 : >EXEC :
(4) For example, to change the pair to DEST1 and SRC2, turn F3 to select 2.
(5) Press F3 to save the pair in the router crosspoint preset. After the preset has been
changed in the router, 2 is displayed under SRC.
EXT I/F : LEVEL : DEST : SRC : TAKE : 3/6
ROUTER : =1 : =1 : =2 : >EXEC :
(6) Repeat steps (2) and (5) to set all destination / source pairs to be saved.
Executing Multiple Switches Simultaneously
(1) In PAGE 3, turn F4 to select EXEC.
(2) Press F4 to execute multiple switches.
EXT I/F : LEVEL : DEST : SRC : TAKE : 3/6
ROUTER : =1 : =1 : =2 : >EXEC :
Displaying Preset Crosspoints
(1) Go to PAGE 4.
(2) Turn F1 to select a level.
EXT I/F : LEVEL : XPT :PRESET : : 4/6
(3) Press F3. The preset crosspoints are displayed. To move among menu pages, use the
page up and down buttons.
ROUTER : 1-1 2-2 3-3 : : 1/XX
PRESET : 4-4 5-5 6-6 : >BACK :
Clearing Preset Crosspoints
(1) In PAGE 3, turn F4 to select CANCEL.
(2) Press F4 to clear the settings.
EXT I/F : LEVEL : DEST : SRC : TAKE : 3/6
ROUTER : =1 : =1 : =2 :>CANCEL:
