6-5. HDMI Output
Video output through the HDMI port can be selected from an M/E program, preview, clean or
key out video, to AUX1-8 and MV.
(1) Double-press AUX1 on the left side of the control panel to display the [SETUP - OUTPUT
- OUT XPT] (1/3) menu.
(2) Press the page down button to go to PAGE 3.
(3) Turn F1 to select a video to be output from the HDMI port.
Available options are:
PGM, PREV, CLEAN, MEKY and AUX1-8 and MV
System Format
Output signal format
1080i
HDTV (1920 x 1080)
720p
HDTV (1280 x 720)
SD
SDTV (720 x 480)
Signals are output at the same frequency as that of the system format.
 Ex. 1
Switcher System Format: 1080/59.94i
To Output the PGM video (at 1920 x 1080 resolution):
OUTPUT : XPT : : 3/3
HDMI OUT: =PGM : :
 Ex. 2
Switcher System Format: 720/50p
To Output the AUX1 video (at 1280 x 720 resolution):
OUTPUT : XPT : : 3/3
HDMI OUT: =AUX1 : :
 Ex. 3
Switcher System Format: SD PAL (625/50)
To Output the MV SDTV video:
OUTPUT : XPT : : 3/3
HDMI OUT: =MV : :
