FOR-A HVS-XT100 User Manual

122
12-5-2. Saving CG WIPE Settings
CG WIPE settings can be saved as WIPE pattern modification settings in Direct Pattern and
in the event memory.
 See section 8-8-3. "Direct Pattern Function"
 See section 15. "Event Memory."
12-5-3. CG WIPE Menu Quick Reference
(1) Display the [WIPE] menu by pressing MENU then WIPE in the SELECT/KEYPAD block.
(2) Turn F1 to select CG WIPE. Press F1 or the page down button to display the submenu
pages.
WIPE :ENABLE : CG : : DUR : 1/3
CG WIPE : =ON : =STL1 : :=30 :
WIPE :SELECT : DELAY : : 2/3
CG WIPE : =KEY1 : =0 : :
WIPE : DELAY : RATE :FDRLINK: : 3/3
CG WIPE : =0 : =30 : =OFF : :
 CG WIPE Parameters
Menu parameter
Default
Setting
Description
Fig. 1
1/3
ENABLE
OFF
OFF, ON
Sets CG WIPE ON/OFF.
-
CG
STL1
STL1-2
Selects a channel through which a CG
is played back.
A
DUR
30
0 to (clip duration)
Sets the CG playback time.
C
2/3
SELECT
KEY1
KEY1-2
Selects a KEY through which a CG is
displayed.
D
DELAY
0
0 to 255
Sets delay time from the start of CG
playback (IN point) until the CG is
displayed on screen (KEYER to ON).
E
3/3
DELAY
(*1)
0
0 to 255
Sets delay time from the start of CG
playback (IN point) to the start of
transition.
F
RATE
(*1)
30
0 to 999
Sets the background transition rate.
G
FDRLINK
OFF
ON, OFF
Sets if CG WIPE can be performed
with the fader lever.
-
(*1) If the sum of the transition delay time and transition rate are longer than the CG playback time, the
transition is forced to end immediately after the CG is finished playing and the image displayed on the
monitor is switched to a PST image.
