Left Bracket
Right Bracket
Front Flange
Rear Flange
Nuts
s8102bl_1
Figure 32
Loosening Flange Nuts 19-Inch, 2-Post Rack Bracket
Step 3
Adjust the width between the front ange and rear ange (on both brackets) to the width of the rack.
Step 4
Use the front ange on each bracket to aach the brackets to the front of the rack at the required posion, as
shown in the following gure.
Note: Do not completely ghten the bolts, the bolts are completely ghtened later in the procedure.
Equipment Installation
Install 19-Inch, 2-Post Rack Rail Kit
108
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
